CALT P3015 Tiny Size Contactless Hall Effect 360 ° Angle Sensor Encoder 3mm Shaft 15mm Outer Dia, Voltage 5V DC, Output Signal 0-5V DC
Thumbnail 1Thumbnail 2Thumbnail 3Thumbnail 4Thumbnail 5

CALT P3015 Tiny Size Contactless Hall Effect 360 ° Angle Sensor Encoder 3mm Shaft 15mm Outer Dia, Voltage 5V DC, Output Signal 0-5V DC

4.1/5
Product ID: 400411307
Secure Transaction
12 interest-free installments with tabby

Details

  • Brand
    CALT
  • Material
    Aluminum Steel
  • Maximum Supply Voltage
    5 Volts (DC)
  • Measurement Accuracy
    0.3%
  • Measuring Range
    360 degrees
5V DC stable output signal
📏15mm ultra-compact diameter
🔄360° continuous angle sensing

Description

🔧 Small size, big precision — never miss an angle!

  • CONTACTLESS DURABILITY - Hall effect sensor ensures smooth, wear-free operation even in harsh environments.
  • PLUG PLAY SIMPLICITY - Easy surface mount installation with stable 0-5V analog output for instant integration.
  • SEAMLESS 360 SENSING - Absolute angle measurement with zero dead zones for flawless rotation tracking.
  • INDUSTRIAL GRADE RESILIENCE - Built to withstand vibration, shock, water, oil, and strong magnetic fields without faltering.
  • MICRO PRECISION MACRO IMPACT - Tiny 15mm outer diameter fits seamlessly into tight industrial spaces.

The CALT P3015 is a compact, contactless Hall effect angle sensor encoder with a 15mm diameter and 3mm shaft, delivering precise 360° absolute angle measurement. Operating at 5V DC with a 0-5V analog output, it offers 0.3% accuracy and robust performance in harsh industrial environments including vibration, shock, and strong magnetic fields. Ideal for advanced machinery control in robotics, construction, and manufacturing.

Specifications

BrandCALT
MaterialAluminum Stainless Steel
Maximum Supply Voltage5 Volts (DC)
Measurement Accuracy0.3%
Measuring Range360 degrees
Mounting TypeSurface Mount
Output Typeanalog
Specific Uses For Productinjection molding machine, crane torque control, Valve, test pedals, Robot arms, PTZ control, paper machinery, textile machinery, construction machinery
UPC759972713745
ManufacturerCALT
StyleAngle Sensor
Country of OriginUSA
Model numberP3015
ColourGreen
Number of Memory Sticks1
Special Featuresmall size
Item Weight23 g
Package Dimensions11.94 x 10.16 x 1.27 cm; 23 g
Item model numberP3015
Voltage5 Volts
Are batteries included?No

Have a Question? See What Others Asked

What type of connector is used to connect signal wires to the sensors nubs?
What is the maximum rpm for this device?
All the dimensions are shown except the height of the signal pins. can you tell us the measurements of the pins and the total sensor height?
Is this limited to a single revolution or can it revolve in the same direction continuously?
